RW1500 Transplanter

Automation

RW1500 Transplanter

The RW1500 Transplanter features advanced electronics and wireless technology for maximum flexibility and efficiency. Up to 24 independent fingers with 1500mm spread transplant up to 24,000 plugs per hour.

Pinching spade gripper design requires no push-up pins, ensuring accurate plant placement and healthy growth. Quick changeovers, plug tray and finish container swaps in minutes. User-friendly touchscreen with electronic depth and height adjustments. Reduces labor costs and boosts throughput.

For pricing and additional information, contact the AdeptAg Sales team.

Contact For Quote

PDF Brochure

Layout Drawing

Details

- High-Speed Transplanting – Up to 24,000 plugs per hour (rate depends on plug tray and finish container specs)
- Independent Finger Movement – Up to 24 fingers with max spread of 1500mm (57.5″)
- Wireless Communication – Seamless component connectivity enhances responsiveness and precision
- Quick Changeovers – Plug tray and finish container changes completed in minutes
- Pinching Spade Gripper – Does not require push-up pins; ensures accurate plant placement
- Touchscreen Control – User-friendly graphical interface for easy operation and adjustments
- Electronic Adjustments – Transplanting depth and plug tray height adjust electronically
Throughput: Up to 24,000 plugs/hour
Finger Configuration: Up to 24 fingers
Max Finger Spread: 1500mm (57.5″)
Electrical: 230 VAC, 3-phase, 16 amps
Air Requirements: 6 CFM

Plug Trays: 512 to 50 cell trays
