14 Foot Water Tunnel System

The 14 Foot Water Tunnel provides controlled watering for flats, trays, pots, and baskets—with extended dwell time for heavier irrigation needs. Available in 16″ and 22″ widths as either 14-foot powered conveyor or 7-foot powered plus 7-foot gravity roller. Standard variable speed up to 80 ft/min, 4-bar manifold, and drain pans. Wires into line controls—watering stops/starts with production to prevent over/under-watering. Accommodates containers up to 31.5″ tall including hanging baskets.

For pricing and additional information, contact the AdeptAg Sales team.

Details

  • Extended Dwell Time

    14-foot length provides longer watering exposure than 7-foot model for heavier irrigation needs.

    Two Configuration Options

    14' powered conveyor belt, or 7' powered belt with 7' gravity roller conveyor.

    Production Line Integration

    Wires into line controls so watering starts/stops automatically with production; prevents over or under-watering.

    No Water Waste

    Limit switch controls water flow; water only runs when product is present.

    Four Independent Water Curtains

    Each of 4 laser-drilled water bars individually controllable from fully open to fully closed.

    Variable Speed Conveyor

    Up to 80 feet per minute on 16" or 22" wide belt.

    Tall Container Capability

    Accommodates containers up to 31.5" tall; handles hanging baskets with hangers.

    Stainless Steel Construction

    Built for wet environment durability with integrated drain pan.

    • Belt widths: 16″ or 22″
    • Max container width: 17.5″ (16″ model) or 23.5″ (22″ model)
    • Max container height: 31.5″
    • Power: 110 VAC

    Options: 6-bar water manifold, Tee-Jet nozzles, filter box, 21’/28’/35′ tunnel lengths
